Abstract

Background

The force required for a sword to penetrate the human chest was identified as an important issue for the defense in a case of homicide by stabbing. Previous literature on penetration force had tested knives but not swords.

Objective

The objective of the current study was to determine the peak force during penetration of a surrogate for human tissue with a ceremonial sword.

Methods

The sword was secured to an MK-10 Tensile Tester and forced to penetrate a pork rib cut at speeds of 350 mm/min and 1100 mm/min, including both regions of rib and cartilage for pork ribs without skin or covered with a layer of porcine skin.

Results

In the case of the pork ribs without skin, the mean peak penetration force at a speed of 350 mm/min was 11.0 N compared to a mean of 10.5 N at a speed of 1100 mm/min. The distributions of peak penetration forces at the two speeds were not significantly different. In the case of the pork ribs covered with porcine skin, the mean peak penetration force at a speed of 350 mm/min was 50.0 N compared to a mean of 47.6 N at a speed of 1100 mm/min. The distributions of peak penetration forces at the two speeds were again not significantly different.

Conclusion

Forces of less than 50 N would be required for a ceremonial sword to penetrate the tissues of the human chest, although there is a risk of penetration for forces as low as 5 N when the effect of the porcine skin is not considered. Furthermore, the force required for penetration did not vary significantly over a three-fold speed of penetration.

Loading

Article metrics loading...

/content/journals/cfs/10.2174/0126664844267345240105094842
2024-01-01
2025-02-28
Loading full text...

Full text loading...

References

  1. Ben AbderrahimS. TurkiE. HaddajiA. GhzelR. Criminal death by stabbing in the region of Kairouan, Tunisia: A retrospective study, 2008-2018.Tunis. Med.2021991211671173 35288923
    [Google Scholar]
  2. BurkeM.P. BaberY. CheungZ. FitzgeraldM. Single stab injuries.Forensic Sci. Med. Pathol.201814329530010.1007/s12024‑018‑9982‑x 29713941
    [Google Scholar]
  3. VassaliniM. VerzelettiA. De FerrariF. Sharp force injury fatalities: A retrospective study (1982-2012) in Brescia (Italy).J. Forensic Sci.20145961568157410.1111/1556‑4029.12487 24712913
    [Google Scholar]
  4. AmbadeV.N. GodboleH.V. Comparison of wound patterns in homicide by sharp and blunt force.Forensic Sci. Int.20061562-316617010.1016/j.forsciint.2004.12.027 16122892
    [Google Scholar]
  5. GillJ. CataneseC. Sharp injury fatalities in New York City.J. Forensic Sci.200247355455710.1520/JFS15295J 12051335
    [Google Scholar]
  6. HuntA.C. CowlingR.J. Murder by stabbing.Forensic Sci. Int.199152110711210.1016/0379‑0738(91)90102‑O 1783333
    [Google Scholar]
  7. MoarJ.J. Homicidal penetrating incised wounds of the thorax. An autopsy study of 52 cases.S. Afr. Med. J.19846510385389 6701694
    [Google Scholar]
  8. HeckmannV. EngumV. SimonG. PoórV.S. TóthD. MolnarT.F. Piercing the surface: A mechanical analysis of stabbing with household tools.J. Forensic Sci.20236841218122710.1111/1556‑4029.15313 37306358
    [Google Scholar]
  9. GittoL. SerinelliS. WernerF.W. OrdwayN.R. StoppacherR. Determination of the force required to produce stab “wounds” in fruit com-pared with cadaveric chest tissue.Am. J. Forensic Med. Pathol.202243431131410.1097/PAF.0000000000000766 35588165
    [Google Scholar]
  10. GittoL. SerinelliS. WernerF.W. OrdwayN.R. StoppacherR. Determination of force required to produce stab wounds in cadaveric chest tissues.Am. J. Forensic Med. Pathol.202142431832310.1097/PAF.0000000000000680 34793408
    [Google Scholar]
  11. NolanG. HainsworthS.V. RuttyG.N. Forces generated in stabbing attacks: An evaluation of the utility of the mild, moderate and severe scale.Int. J. Legal Med.2018132122923610.1007/s00414‑017‑1702‑7 29038886
    [Google Scholar]
  12. BolligerS.A. KneubuehlB.P. ThaliM.J. EggertS. SiegenthalerL. Stabbing energy and force required for pocket-knives to pierce ribs.Forensic Sci. Med. Pathol.201612439439810.1007/s12024‑016‑9803‑z 27503509
    [Google Scholar]
  13. GilchristM.D. KeenanS. CurtisM. CassidyM. ByrneG. DestradeM. Measuring knife stab penetration into skin simulant using a novel biaxial tension device.Forensic Sci. Int.20081771526510.1016/j.forsciint.2007.10.010 18093771
    [Google Scholar]
  14. HainsworthS.V. DelaneyR.J. RuttyG.N. How sharp is sharp? Towards quantification of the sharpness and penetration ability of kitchen knives used in stabbings.Int. J. Legal Med.2008122428129110.1007/s00414‑007‑0202‑6 17899151
    [Google Scholar]
  15. AnkersenJ. BirkbeckA.E. ThomsonR.D. VanezisP. Puncture resistance and tensile strength of skin simulants.Proc. Inst. Mech. Eng. H1999213649350110.1243/0954411991535103 10635698
    [Google Scholar]
  16. Ní AnnaidhA. CassidyM. CurtisM. DestradeM. GilchristM.D. A combined experimental and numerical study of stab-penetration forc-es.Forensic Sci. Int.20132331-371310.1016/j.forsciint.2013.08.011 24314495
    [Google Scholar]
  17. O’CallaghanP.T. JonesM.D. JamesD.S. LeadbeatterS. HoltC.A. NokesL.D.M. Dynamics of stab wounds: force required for penetration of various cadaveric human tissues.Forensic Sci. Int.19991042-317317810.1016/S0379‑0738(99)00115‑2 10581723
    [Google Scholar]
  18. KarrayN. DedouitF. DuboisC. SavallF. TelmonN. Homicide by unusual‐edged weapons: Forensic considerations of two cases.J. Forensic Sci.202166139840210.1111/1556‑4029.14573 32986854
    [Google Scholar]
  19. WysozanT.R. PrahlowJ.A. The cane sword.J. Forensic Sci.201863130931110.1111/1556‑4029.13528 28464324
    [Google Scholar]
  20. RaulJ.S. BerthelonL. GerautA. TracquiA. LudesB. Homicide attempt with a Japanese samurai sword.J. Forensic Sci.2003484200231810.1520/JFS200231812877304
    [Google Scholar]
